High Efficiency Lightweight Durable Die-Cast Aluminum HAWT Turbine Low Wind Start 3/5 Blade Options Wind Generators

High Efficiency Lightweight Durable Die-Cast Aluminum HAWT Turbine Low Wind Start 3/5 Blade Options Wind Generators

SDT-V | Sidite Wind Power

Overview
Recommended Products

Product Descirption

SDT-V | Sidite Wind Power

The characteristic:

1.Low starting wind speed, high utilization rate of wind energy, small size, light weight, beautiful appearance, low running vibration.
2. Hoop or flange can be selected for the rotary bodywhich is convenient for various installation requirements.
3 The wind rotor blades are precision injection-mold-ed by new technology, with optimized aerodynamic shape design and structure design, three or five blades can be freely selected, the wind energy utilization coefficient is high, and the annual power generation is increased.
4. The casing is made of die-cast aluminum alloy asa whole, with customized bearing swivel, stronger typhoon resistance and safe and reliable operation.
5. The generator adopts the patented permanentmagnet rotor alternator, with a special stator design.which effectively reduces the resistance torque of the generator, thereby reducing the starting wind speed:at the same time, the wind wheel and the generator have a better match Features to ensure there liability of the unit operation.
6. The intelligent tracking technology of wind powergeneration efficiency can be selected, which caneffectively adjust the current and voltage, and the power conversion rate is high.

Detailed Images

Type	SDT-100SV1	SDT-200SV1	SDT-200SV2	SDT-300SV2
Rated Power	100W	200w	200W	300W
Rated Voltage	12/24V	12/24V	12/24V	12/24V
Start-up Wind	1.8m/s	1.8m/s	2m/s	2m/s
Survival Wind	40m/s	40m/s	40m/s	40m/s
Wheel diameter	0.48m	0.48m	0.65m	0.65m
Wheel height	0.88m	1. 1m	1. 1m	1. 3m
Blades	10	12	10	12
Generator	NdFeB three-phase AC permanent magnet generator
Protection	Electromagnetic
Working tep	-40℃~80℃

High Efficiency Lightweight Durable Die-Cast Aluminum HAWT Turbine Low Wind Start 3/5 Blade Options Wind Generators manufacture

High Efficiency Lightweight Durable Die-Cast Aluminum HAWT Turbine Low Wind Start 3/5 Blade Options Wind Generators details
