SD-S(SD-G) Eco-Friendly Economical Solar Water Heater High Pressure Polyurethane Non-Pressurized Hotels Free-Standing

SD-S(SD-G) Eco-Friendly Economical Solar Water Heater High Pressure Polyurethane Non-Pressurized Hotels Free-Standing

SD-S(SD-G) | Non-pressurized Solar Water Heater

Overview
Recommended Products

Product Descirption

SD-S(SD-G) | Non-pressurized Solar Water Heater

The characteristic:

1. With intelligent controller.

2. Easy to install for flat roof and pitched roof, auxil-iary heating by electrical heater.

3. High pressure polyurethane foaming with thickness 55mm.

4. Stable and reliable performance, well wind resistance.

5.SUS304-2B inner tank, silicon seals. 6.SUS304-2B/BA outer tank, against rust and corrosion. 7.Eco and economical, improves the environmentand save your fuel cost.

Model	SD-S-10	SD-S-15	SD-S-18	SD-S-20	SD-S-24	SD-S-25	SD-S-30
Tube Quantity (pcs)	10	15	18	20	24	25	30
Water Tank
Net Capacity (L)	80	120	140	155	185	195	230
Gross Capacity(L)	105	155	185	205	245	255	305
Diamater Of Inner/Outer Tank (mm)	φ360/φ470
Length Of Outer Tank L(mm)	935	1310	1535	1685	1985	2060	2435
Length Of Inner Tank L(mm)	795	1170	1395	1545	1845	1920	2295
Material Of Inner Tank(mm)	SUS304-2B/SUS316L
Material Of Outer Tank	Stainless Steel Plate/Color Steel Plate
Material Of Insulation	Polyurethane
Vacuum Tube
Diameter/Length(mm)	φ58/1800
Material	High Borosilicate Glass3.3
Frame	2 Feets(Left-To-Right)							3 Feets(Left-Middle-Right)
Material	Stainless Steel/Galvanized Steel
Angle	45°
Item Size
A(mm)	935	1310	1535	1685	1985	2060	2435
B(mm)	730	1110	1335	1485	1785	1860	2235
C(mm)	1700	1700	1700	1700	1700	1700	1700
C/2(mm)	——		— —	——	892.5	930	1255
D(mm)	1430	1430	1430	1430	1430	1430	1430

Detailed Images

SD-S(SD-G) Eco-Friendly Economical Solar Water Heater High Pressure Polyurethane Non-Pressurized Hotels Free-Standing manufacture

SD-S(SD-G) Eco-Friendly Economical Solar Water Heater High Pressure Polyurethane Non-Pressurized Hotels Free-Standing details

About Us

SIDTE Energy Co., Ltd

SIDITE Energy Co., Ltd., founded in 2000, is located in JiaXing City, Zhejiang Province.
The company specializes in the production of solar water heaters, solar collectors, solar power generation systems, and various heat pump products, including domestic, commercial, and industrial heat pumps.

Equipped with the most advanced production line and the 6 Pump Performance Comprehensive Laboratory" in China.20ITE recognized as a national high-tech enterprise, boasting 24 years of manufacturing experience.Currently, 50% of its products are exported to international market.

Our products have been awarded numerous certifications, including the Solar Keymark, CE,CCC,ISO9001, and ISO14001, and have been shipped to over 50 countries, such as Germany, the Holland, Poland, Finland, Brazil,Argentina,Australia, and Kenya.

Ensuring the highest level of customer satisfaction is our primary objective. We are committed to upholding the principles of"customer first, credit first" to establish and foster mutually beneficial cooperative relationships with clients worldwide.

Sidite makes your life green!
