High Efficiency 5-Blade HAWT Wind Turbine Lightweight Durable Die-Cast Aluminum Smart Tracking Technology for Generation Wind

High Efficiency 5-Blade HAWT Wind Turbine Lightweight Durable Die-Cast Aluminum Smart Tracking Technology for Generation Wind

SDT-Q | Sidite Wind Power

Overview
Recommended Products

Product Descirption

SDT-Q | Sidite Wind Power

The characteristic:

1. Low starting wind speed and high utilization rateof wind energy; Small size, light weight, beautiful appearance, and low operating vibration.
2. The rotating body can be selected as a hoop orflange, which is convenient for various installation requirements.
3. The wind turbine blades adopt a new process ofprecision injection molding, combined with optimizedaerodynamic shape design and structural design.Three or five blades are freely selected, with high wind energy utilization coefficient and increased annual power generation.
4. The casing is integrally formed with die-castingaluminum alloy,combined with customized bearingrotations, with stronger typhoon resistance and safe and reliable operation.
5.The generator adopts a patented permanent magnet rotor AC generator with a special stator design,effectively reducing the resistance torque of the generator and thus reducing the starting wind speed; At the same time, the wind turbine and generator have better matching characteristics, ensuring the reliability of unit operation.
6. The intelligent tracking technology of wind powergeneration efficiency is adopted to effectively regulate the current and voltage, and the power generation conversion rate is high.

Detailed Images

Type	SDT-100Q1	SDT-200Q1	SDT-300Q4	SDT-400Q4
Rated Power	100W	200W	300W	400W
Rated Voltage	12/24V	12/24V	12/24V	12/24V
Start-up Wind	2m/s	2m/s	2.5m/s	2.5m/s
Survival Wind	45m/s	45m/s	45m/s	45m/s
Wheel diameter	0.98m	0.98m	1.2m	1.2m
Wheel height	0.87m	0.87m	0.96m	0.96m
Blades	9	9	7	7
Generator	NdFeB three-phase AC permanent magnet generator
Protection	Electromagnetic
Working tep	-40℃~80℃

High Efficiency 5-Blade HAWT Wind Turbine Lightweight Durable Die-Cast Aluminum Smart Tracking Technology for Generation Wind details

About Us

High Efficiency 5-Blade HAWT Wind Turbine Lightweight Durable Die-Cast Aluminum Smart Tracking Technology for Generation Wind manufacture

SIDTE Energy Co., Ltd

SIDITE Energy Co., Ltd., founded in 2000, is located in JiaXing City, Zhejiang Province.
The company specializes in the production of solar water heaters, solar collectors, solar power generation systems, and various heat pump products, including domestic, commercial, and industrial heat pumps.

Equipped with the most advanced production line and the 6 Pump Performance Comprehensive Laboratory" in China.20ITE recognized as a national high-tech enterprise, boasting 24 years of manufacturing experience.Currently, 50% of its products are exported to international market.

Our products have been awarded numerous certifications, including the Solar Keymark, CE,CCC,ISO9001, and ISO14001, and have been shipped to over 50 countries, such as Germany, the Holland, Poland, Finland, Brazil,Argentina,Australia, and Kenya.

Ensuring the highest level of customer satisfaction is our primary objective. We are committed to upholding the principles of"customer first, credit first" to establish and foster mutually beneficial cooperative relationships with clients worldwide.

Sidite makes your life green!
