SC-HP(SC-H) | Heat Pipe Solar Collector

Overview
Recommended Products

Product Descirption

SC-HP(SC-H) | Heat Pipe Solar Collector

The characteristic:

1. Twin-glass vacuum tubes: Reliable, efficient, high temperature resistant, anti-freezing.
2. There is no water in the vacuum tube, the system will still work even the tube broken.
3. Red copper heat pipe, one-way transferring, fast heat transfer, less heat loss, low temperature resistance, it
can be used in -35℃.
4. Aluminum alloy manifold and bracket, corrosion resistance, easy to install. It’s suitable for flat and sloping
roof.
5. High temperature resistant polyurethane foaming / rock wool high density, good thermal insulation properties.
6. High quality copper manifold, its testing pressure is 1MPa.
7. Solar Keymark certification approved .
8. Eco and economical, Improves the environment and save your fuel cost.

Model	SC-HP-10 (SC-H-10)	SC-HP-15 (SC-H-15)	SC-HP-18 (SC-H-18)	SC-HP-20 (SC-H-20)	SC-HP-24 (SC-H-24)	SC-HP-25 (SC-H-25)	SC-HP-30 (SC-H-30)
Tube Quantity(pcs)	10	15	18	20	24	25	30
Vacuum Tube Diameter/Length (mm)	φ58/1800
Vacuum Tube Material	High Borosilicate Glass 3.3
Heat Pipe (mm)	φ14/1700
Insulation Material/Thickness (mm)	Polyurethane Foaming/Rock Wool /40
Rated Pressure (mpa)	0.6
Aperture Area (m²)	1	1.5	1.8	2	2.4	2.5	3
Gross Area (m²)	1.56	2.3	2.74	3.04	3.63	3.77	4.51
Power(w)1000w/m²	620	870	1047	1165	1401	1457	1748
Net Weight(kg)	38.25	50.75	59.75	64.75	79	83.35	98.7
A(mm)	895	1270	1495	1645	1945	2020	2395
B(mm)	800	1175	1400	1550	1850	1925	2300
C(mm)	725	1100	1325	1475	1775	1850	2225
C/2(mm)	——	— —	— —	— —	887.5	925	1112.5
D(mm)	1980	1980	1980	1980	1980	1980	1980
E(mm)	1240	1240	1240	1240	1240	1240	1240
F(mm)	1470	1470	1470	1470	1470	1470	1470

Detailed Images

SC-HP High-Performance IPX7 Waterproof Aluminum Frame Solar Water Heater Evacuated Tube Solar Collector Rock Wool Outdoor Hotel supplier

SC-HP High-Performance IPX7 Waterproof Aluminum Frame Solar Water Heater Evacuated Tube Solar Collector Rock Wool Outdoor Hotel manufacture

SC-HP High-Performance IPX7 Waterproof Aluminum Frame Solar Water Heater Evacuated Tube Solar Collector Rock Wool Outdoor Hotel details
